    2.54 MM Pitch Dual Row Round Pin Header 180 Degree DIP Connector Full Gold

    Ask Lasest Price
    Brand Name : DZ
    Model Number : 180 Degree DIP Full Gold Connector
    Certification : ISO9001 | CE | ROHS | REACH | MSDS | SGS
    Price : 100 - 999 Pieces = $0.45, 1000 - 4999 Pieces = $0.35, 5000 - 9999 Pieces = $0.32, ≥ 10000 Pieces = $0.29
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Supply Ability : 10000 Piece/Pieces per Week 180 Degree DIP Full Gold Connector
    Delivery Time : 7 Days
    • Product Details
    • Company Profile

    2.54 MM Pitch Dual Row Round Pin Header 180 Degree DIP Connector Full Gold

    2.54 MM Pitch Dual Row Round Pin Header 180 Degree DIP Full Gold Connector

    # 180 Degree DIP Full Gold Connector Properties

    1.MATERIAL:
    1-2.HOUSING:PPS+30%G.F.
    1-3.TEMINARL: Brass
    2.PLATING SPECIFICATION
    2-1.TERMINAL: 1U" Full GOLD PLATED.
    3.MECHANICAL PERFORMANCE
    3-1.INSERTION FORCE: 5N~20N.
    3-2.WITHDRAWAL FORCE: INITIAL 8N~20N , AFTER 1000 MATING CYCLES 6N~20N.
    3-3.DURABILITY: 10000 CYCLES.
    4.ELECTRICAL PERFORMANCE
    4-1.CURRENT RATING: 3A.
    4-2.CONTACT: 40mΩ MAX(INITIAL).
    4-3.INSULATION RESISTANCE:UNMATED: 100MΩ MIN.
    4-4.DIELECTRIC WITHSTAND VOLTAGE: 100V/AC.
    5.OPERATING TEMPERATURE RANGE: -40°C~105°C.
    6.RoHS COMPLIANT OR HALOGEN FREE COMPLIANT.



    2.54 MM Pitch Dual Row Round Pin Header 180 Degree DIP Connector Full Gold



    FAQ
    Q1: When Can I Get the Price?
    A1: We usually quote within 12 hours after we get the inquiry. If you are very urgent to get the price, please call us or tell us your email, so that we will regard your inquiry priority.
    Q2: Can I Have a Sample Order?
    A2: Yeah, welcome order samples to test and check quality.

    Q3: Could I Print My Logo on the Product?
    A3: Yes, we welcome OEM/ODM, please inform us formally before our mass production and confirm the design firstly based on our samples.
